vulcanizing equipments
rotary curing machine-ks8凯发官方网站
| 型号model 项目item | dlg700×1400-1800 | dlg1100×2000 | dlg1500×2000-2500 | dlg2000×2500-4200 | ||
| 制品最大宽度 max. product width | ㎜ | 1200-1600 | 2000 | 2000-2500 | 2500-4200 | |
| 制品最大厚度 max. product thickness | ㎜ | 5 | 8 | 12 | 12 | |
| 硫化鼓直径 drum dia. | ㎜ | 700 | 1100 | 1500 | 2000 | |
| 硫化鼓工作宽度 drum working width | ㎜ | 1400-1800 | 2200 | 2350-2750 | 2750-4200 | |
| 压力带总拉力 total pulling force of steel belt | t | 38-49 | 90 | 93.6-117 | 120-144 | |
| 硫化鼓线速度 the linear speed of vulcanizing drum | m/min | 1.12-0.04 | 0.06-1.8 | 0.175-3.14 | 0.24-4.7 | |
| 使用蒸汽压力 steam pressure | mpa | 0.6 | ≤0.8 | ≤1 | ≤1 | |
| 硫化温度 vulcanizing temperature | ℃ | 1140-160 | 140-160 | 160-180 | 160-180 | |
| 主电机功率 main motor power | kw | 4、5.5 | 7.5 | 7.5-11 | 15～30 | |
| 外形尺寸 overall dimensions | l | ㎜ | 8300 | 10000 | 1350 | 18600 |
| w | ㎜ | 4400-4830 | 4900 | 5200 | 4650-6200 | |
| h | ㎜ | 2100 | 2600 | 6085 | 6285 | |
| 约重about weight | t | ～20-30 | ～42 | ～79 | ～80-126 | |
